Lecture 12 : Maximum Gain Amplifier Design | ADS Simulation

Learn Verilog with Practice : https://www.whyrd.in/s/store In this maximum gain amplifier design ads simulation tutorial video we have taken the lecture 11 example and explained the process flow of design using ADS simulation. We have extensively discussed the application of ADS smith chart tool in analysing stability of our device, impedance matching and deciding upon gain using different type of gain circle available in ADS smith chart tool. In our follow-up lecture we will continue same example and demonstrate ADS optimization process and ADS layout basics.
In our Lecture 11, we have explained about microwave amplifier bilateral design method, here we have designed one maximum transducer gain amplifier using serenade simulation with the help of mild automation from matlab script. We also briefly discussed about smith chart matching, how to unilateral FOM and stability analysis using mu prime or other stability factor.
Lecture 11 link :    • Lecture 11: Maximum Gain Amplifier Design ...
Moreover in our previous video on this playlist of channel whyRD we have already explained concept of stability and smith chart stability circle of microwave amplifier design . We also have discussed about Constant Gain circle different type of power gain, difference between unilateral and bilateral design and unilateral FOM.We used microwave amplifier design by Gonzalez as our reference
matlabScript: https://drive.google.com/file/d/1dhkQ...
Lecture 5 (for s2p file details):    • Lecture 5 |Constant Gain Circle EXAPMPLE u...
Lecture 9(matlab script detail) :    • Lecture 9 |Stabilize device using stabilit...
Time Stamps
00:00. This video content list
00:43 Example simulation in ADS
01:18 Stability analysis
01:55 Making first cut Schematic
04:10 Selecting gammaS/L
09:24 Matchings
16:30 Practical Schematic
