Designing 3-phase motor driver
Автор: Ilusys Systems
Загружено: 2018-05-05
Просмотров: 34946
Описание:
I designed quite efficient motor driver, so I am sharing
Hopefully, there isn't too much bullshit there, and this will help someone...
Keep in mind, that there are dedicated IC's made for this purpose also look at other designs as well. This design is quite primitive and buitl for specific purpose, so it may not suit your needs...
Got some files here, with probably a lot of junk (previous versions and intermediate versions, which I decided to not to include in this vid).
https://drive.google.com/open?id=13At...
The boards are routed by hand without linking with sch. Sorry for that...
