F150 Upgraded Cluster Install, Odometer Programming, Select-Shift Shifter Install

Upgrading the instrument cluster in the 2014 F150 from the base model green/black screen to the 4" color display. We're also installing the select shift column shifter that we already enabled in Forscan in the video where we programmed in the remote start and the steering wheel buttons. Finally we used a TL866II Plus EEPROM programmer and programmed the odometer to match the truck's current cluster. Information is shown ONLY for you to keep your existing mileage on a replacement instrument cluster.

DO NOT MISREPRESENT THE ODOMETER ON ANY VEHICLE!

I used XGPro for the download and programming of the chip. It's free. Once the bin is downloaded I used HxD to compare BIN files and change what was necessary. I also used Tachosoft to check for the correct code to edit, but that isn't necessary if you are just copying the miles from one cluster to the other. If the old cluster was broken completely, then you may need Tachosoft to give you the hex code for the miles you had already.

These are the eeprom programmer parts I used:
Socket Adapter - https://amzn.to/463UuSg
Programmer - https://amzn.to/3sLbEFY
As an Amazon Associate I earn from qualifying purchases. I earn a small commission if you click these links and make a purchase at no additional cost to you.

0:00 Junkyard
2:00 Installation
3:06 Airbag Removal Cruise Control
4:07 Shifter Handle
5:07 Cluster Removal
5:51 EEPROM Locations
8:52 Software BIN Compare
10:54 Final Test
