How to Use an OTDR with an Optical Switch Box for Basic Measurements

The AQ3550 Optical Switch Box from Yokogawa Test&Measurement is a 12-channel OSW that, when paired with an optical time domain reflectometer, improves workflow efficiency. In this video we demonstrate how to use the AQ1210 Optical Time Domain Reflectometer in conjunction with the AQ3550's Multi Fiber Project function, which enables continuous measurements of 12 optical fibers and determine pass or fail results.

Please note that product specifications may change without notice due to firmware updates, etc. For the most up-to-date information, please visit the firmware download page (accessible via the link below).

LEARN MORE
AQ1210 Series Optical Time Domain Reflectometer
https://tmi.yokogawa.com/solutions/pr...

AQ3550 Optical Switch Box
https://tmi.yokogawa.com/solutions/pr...

_______________________________________________________

Connect with Yokogawa Test&Measurement on LinkedIn:
  / yokogawa-test&measurement

Contact Yokogawa Test&Measurement:
https://tmi.yokogawa.com/contact/?utm...

Yokogawa has been developing measurement solutions for 100 years and consistently finds new ways to give R&D teams the tools they need to gain the best insights from their measurement strategies. The company has pioneered accurate power measurement throughout its history and is the market leader in digital power analyzers.

Yokogawa Test&Measurement instruments are renowned for maintaining high levels of precision and for delivering value far longer than the typical shelf life of such equipment. The Precision Makers of Yokogawa Test&Measurement believe that precise and effective measurement lies at the heart of successful innovation - and has focused its own R&D on providing the tools that researchers and engineers need to address challenges great and small.

_______________________________________________________

Chapters:
00:00 Connection Configuration
01:17 Multi Fiber Project Function
02:18 Setting Procedure
04:24 Automatic Channel Switching
05:56 Analysis
