Display for Orange Pi Zero
Автор: Kaspars Dambis
Загружено: 2017-03-05
Просмотров: 147376
Tutorial: https://kaspars.net/blog/spi-display-...
After figuring out the GPIO pin names of the Orange Pi Zero expansion port (see https://kaspars.net/6265) it is relatively easy to configure any TFT display as a FBTFT device attached over the SPI bus as long as you know the name of the chip used to drive the LCD screen.
Similar display with the same ILI9340 LCD driver from Waveshare https://www.waveshare.com/product/3.2...
Mapping GPIO ports on Allwinner SoC: https://kaspars.net/blog/linux/orange...
Note that Orange Pi Zero also has analog composite video output which I haven't tested.
