TDA7375 2X37 WATT, CLASS AB AMPLIFIER
Автор: Edi Restanto
Загружено: 2025-07-25
Просмотров: 428
TDA7375A Power Amplifier Stereo 2X 37W Dual Bridge Class-AB TDA7375 Audio Amplifier
Hi-Fi Audio Power Amplifier 2X37W Stereo Double Bridge
Driver : TDA7375A
Output : 2x37W(4 Ohm) EIAJ, Max 2X73W(4 Ohm) pada 14.4V
Mode : Dual Bridge (non-Coupling Capacitor)
Speaker : 4~8 Ohm
Power Supply : 12-15V DC
Features :
-Minimum External Component
-No Bootstrap Capacitors
-No Boucherot Cells
-Internally Fixed Gain Control (26dB BTL)
-Stand-by function
-No Audible POP (jedug) during standby operation
-Diagnostic Facilities
Protections :
-Output (AC/DC) to GND Short Circuit protection
-Soft Short at Turn ON (anti-jedug)
-Over-heat protection
-Load dump voltage Suege protection
-Very inductive loads protection
-Fortuitous Open GND protection
-Reversed Battery Protection (Tegangan terbalik)
-ESD protection
https://imup.cc/gH8vgg
#tda7375 #amplifier #amplifierclassab
