LED indicators on KTM 500 EXC-F using correct KTM connectors
Автор: Keith Jobson
Загружено: 2019-04-15
Просмотров: 24540
Here I show you how I fitted micro rear indicators to the KTM 500 EXC-F, and what the proper connectors are.
Connector:
JST 02R-JWPF-VSLE-S
This is the female connector that you need for your indicators.
(02R for "receiver")
The corresponding male version is 02T.
Search ebay for "Mini JST06R-JWPF-VSLE-D Connector Kits 2-8 Way Pin Motorbike"; this is what I used. Yes the title is not quite correct but you get the options for correct type in the listing. Select 02R.
Version 1 LED light in the video is a cheap $5 unit I found on ebay. I like the orange lens. It simply sticks on via double sided tape. Just how durable this is will have to be seen.
Version 2 LED light is from mxstore.com.au, item is "MCS Universal Micro Teardrop Clear Lens Flush Mount Indicator Pair". This is stick-on, and also has two tabs. To mount this one I drilled two holes into the guard and the tabs locate in the holes. I suspect this one will never move.
