Phase Inverters....for the Common Man
Автор: Uncle Doug
Загружено: 2014-04-23
Просмотров: 251950
This video describes the purpose and design of three different common phase inverter circuits: Split Load or Cathodyne, Paraphase, and Long-Tailed Pair. Simplified diagrams are used to explain how each circuit functions, and then then these circuits are demonstrated within schematics of classic tube amplifiers. The language is basic and simple analogies are utilized to clarify concepts.
If you enjoy videos featuring classic vintage tube amps, jukeboxes, home-built electromechanical marvels, and clear, concise technical presentations, then please subscribe to my channel. You will gain immediate access to about 100 additional videos, and (if you activate the service) you will be notified each time a new video is posted.
NOTE: In the schematic for the LTP PI (at 19:05) I inadvertently left out the plate resistor for the lower output tube.
Thanks for watching !!!
