How To Diagnose GPU Faults : A Complete Guide With Practical Example Using Dead RTX 3060

This is the RTX 3060 I got from the Car Boot Sale for just €20. I diagnosed the fault on the last video. This time we take a look at GPU repair in general with a Guide To Graphics Card Repair and use those techniques to repair our card. So we have a mixture of theory and practical here. Enjoy and learn...

Part one is here
   • RTX 3060 Found At The Car Boot Sale / Flea...

Part two is here
   • RTX 3060 Dead, Not Detected By PC : Can We...
