ControlLogix Reading Data From CompactLogix, SLC-500, & MicroLogix over Ethernet

Автор: Insights In Automation

Загружено: 2020-01-20

Просмотров: 18991

Описание:

Support our channel and gain access to our How-Tos + Q&As: / @insightsia
Shawn shows how to program a ControlLogix with Message Instructions (MSG) to read data from a CompactLogix, SLC-500, and MicroLogix over Ethernet in Episode 29 of The Automation Show.

To see all our articles and videos visit: https://TheAutomationBlog.com
To see our affordable online and in-person courses visit: https://TheAutomationSchool.com

Until next time, Peace!
