FDOTConnect (ORD) Pond Design - Chapter 1

FDOTConnect (ORD) Pond Design - Chapter 1
This video is certified for ORD version 10.08.01.33 and above

Table of Contents:

00:00 - Chapter 1 Introduction
00:42 - Chapter 1 Topics Covered
00:58 - Exercise 1.1
01:15 - Open OpenRoads Designer
01:37 - Open _BlankFile.dgn
01:53 - FDOT Tab for Create File Tool
02:02 - Create File Tool
03:01 - Home Tab for References Tool
03:09 - Attach References Dialog
04:38 - Exercise 1.2
05:34 - Set Active Feature Definition
06:16 - Geometry Tab
06:18 - Offsets and Tapers Dropdown
06:25 - Single Offset Partial Tool
10:46 - Arcs Dropdown
11:11 - Simple Arc Tool
15:21 - Change Feature Definition
15:57 - Complex Geometry Dropdown
16:05 - Complex By Element Tool
17:19 - Set Active Terrain Model
18:00 - Open Profile Window for PondCntl Shape
19:18 - Verticle Group
19:21 - Element Profiles Dropdown
19:28 - Profile By Constant Elevation Tool
20:56 - Set Active Profile
22:00 - Exercise 1.3
22:27 - Verify Template Library
22:32 - Corridors Tab
22:37 - Create Template Tool
22:48 - Choose Template Library
23:35 - Set Current Template
24:15 - Set Active Feature Definition
24:26 - Model Detailing Tab
24:30 - 3D Tools Group
24:33 - Apply Linear Template Tool
26:16 - Open 3D View
26:49 - Exercise 1.4
28:19 - Open References Dialog
28:30 - Turn Off 3D Reference File View
29:10 - View PondCntl Shape Editable Parameters
29:36 - Open Profile View
29:55 - Change Profile Elevation
31:20 - Exercise 1.5
31:35 - Terrain Tab
31:40 - Create Group
31:43 - Additional Methods Dropdown
31:47 - Terrain Model from Design Meshes Tool
33:31 - Thank you for watching
