How to Make: CNC Textured Inlay Sign | ToolsToday

Making a textured inlay "be thankful" sign (plans link below) for a Thanksgiving project on the Stepcraft M.1000 CNC machine using Amana Tool® industrial CNC router bits available on our website, https://www.toolstoday.com/?utm_sourc...

What do you think of how this CNC sign project turned out?

The downloadable and customizable CNC plans are available on our website. It's a super fun and easy way to make a step tool for yourself!

https://www.toolstoday.com/be-thankfu...

With the design file you will be able to make this incredible looking 38” long textured inlay be thankful sign! In this set of plans I will walk you through finding the correct offset needed for your CNC machine to achieve a tight fitting inlay like this. The font used is mentioned in the plans so you can customize the text. You can also size the sign up or down depending on your needs and I will explain how to still get a perfect inlay when doing so.

Feed, Speed & CNC Running Parameters

Amana Tool 46200-K SC Spektra Extreme Tool Life Coated Spiral Plunge 1/8 Dia x 1/2 CH x 1/4 SHK 2 Inch Long Down-Cut Router Bit
https://www.toolstoday.com/v-13777-46...
RPM: 18,000
Feed Rate: 150ipm
Plunge Rate: 75ipm

Amana Tool 46426-K SC Spektra Extreme Tool Life Coated Up-Cut Spiral Ball Nose 1/8 R x 1/4 D x 1/2 CH x 1/4 SHK x 2-1/2 Inch Long x 2 Flute
https://www.toolstoday.com/v-14621-46...
RPM: 18,000
Feed Rate: 100ipm
Plunge Rate: 50ipm

Amana Tool 46202-K SC Spektra Extreme Tool Life Coated Spiral Plunge 1/4 Dia x 3/4 CH x 1/4 SHK 2-1/2 Inch Long Down-Cut Router Bit
toolstoday.com/v-13779-46202-k-bit.html
RPM: 18,000
Feed Rate: 180ipm
Plunge Rate: 90ipm

Amana Tool MR0108 Miniature 45 Degree Chamfer with 3/16 D Ball Bearing x 9/16 D x 1/4 CH x 1/4 Inch SHK Carbide Tipped Router Bit
https://www.toolstoday.com/v-11228-mr...

JessEm Rout-R-Lift II
https://www.toolstoday.com/v-14760-02...

FEIN 72297261090 MultiMaster MM300 Plus Start Set, Corded Oscillating Multi-Tool
https://www.toolstoday.com/v-17616-72...

General Finishes Oil Based Wood Stain, Spiced Walnut, 1 Quart
https://www.toolstoday.com/v-15070-sw...
