WWW.MULLINMACHINERY.COM
TOS SN40c 16″ x 60″ Gap Bed Lathe
Serial# 08 40 1595 0417
Specifications:
Swing Over Bedways: 16″
Swing Over Cross Slide: 8-3/4″
Swing in Gap: Approx. 25″
Distance Between Centers: 60″
Spindle Bore Diameter: 2.04″
Spindle Speeds, Low (12): 22.4 to 1000 RPM
Spindle Speeds, High (12): 45 to 2000 RPM
Inch Feeds (36): .002 to .195
Metric Feeds (2): .189 and .242
Inch Threading (33): 1 to 80
Metric Threading (29): 0.5 to 40
Leadscrew Diameter: 1-1/2″
Tailstock Spindle Diameter: 2-3/4″
Tailstock Spindle Taper: #5MT
Tailstock Spindle Travel: 5″
Spindle Nose: D1-6 Camlock
Equipped with:
Rapid Traverse
10″ TOS 3 Jaw Chuck with ID and OD Jaws
12″ Willis 4 jaw Chuck
Drive Plate
Steady Rest
Follow Rest
Aloris CXA Toolpost Set
Tailstock Chuck
Drive Plate
Coolant Pump
Manuals
**ALL ORIGINAL PAINT**
See this machine and others on our website WWW.MULLINMACHINERY.COM
