Siemens LOGO! Exercise: Interlock Logic for 2 Outputs (Q1 & Q2)

In this Siemens LOGO! PLC tutorial, we solve a classic logic challenge: controlling a motor's Forward (Q1) and Reverse (Q2) rotation using two switches. You will learn how to create a safety Interlock in LOGO! Soft Comfort to ensure only one output is active at a time. We also cover the specific logic required to turn ALL outputs OFF if both switches are pressed simultaneously.
