Mould Repair Yag Laser Welding Machine 400W

Product description
1. Adopt imported ceramic concentrating cavity, high reflectivity, strong energy, high temperature resistance, corrosion resistance and long service life;
2, equipped with 1.5P special chiller, can meet the long-term, high-power welding stability;
3. The base of the workbench is electrically lifted and lowered. The workbench moves using precision ball screw and high-precision straight guide rail. It is light and flexible, with precise positioning and bearing capacity up to 200 kg.
4, the laser head can slide back and forth, manual lifting, the laser head can be easily rotated 180 degrees, convenient to repair any side;
5, remote control all-round control, 360 degree flexible adjustment of welding angle position, suitable for all kinds of mold welding, for large molds, you can use the workbench, directly on the ground or forklift for mold welding, you can repair the welding radius of 1.5 meters, the weight of the number Tons of large molds and equipment
The spare pulley is convenient to move, and can be moved directly to the injection molding machine to directly repair the welding without removing the mold;
6, the welding depth is large, the welding is more firm, the welded part can be fully melted without pores and trachoma, and the repair marks are neat and beautiful.

Maximum laser power: 200W400W
The laser wavelength1064nm
Condenser reflector Imported ceramic condenser
The laser frequency 1-20Hz
The pulse width 0.1-10Ms
Spot adjustment range 0.3-2mm
Aimed at positioning Microscope (optional camera system)
Cold power of cold water mechanism 1.5P
The engine power 8KW
Demand for electricity 380V±5V 50Hz/40A /220V±5V 50Hz/60A
Range of three dimensional load-bearing table 125×100×300mm
bearing capacity of three dimensional load-bearing table 150kg
Manual suspension arm
Lifting height 600mm
stretch scope 3m
External dimensions/net weight
Host computer: 1000×550×1150mm 103kg
cooling-water machine: 550×550×850mm 80kg
Three dimensional load-bearing table: 550×400×700mm 57kg
Manual suspension arm: 1050×1250×1700mm 147kg
