Hybrid conversion of Razor , Maiden flight

Razor of Eachine was converted to Hybrid one.


Before installation of solar cell,
widening of wing was done to install many solar cells.


18 of 1/3 solar cells were installed to each wings in series,


and 18 solar cells of each wings were connected in parallel.


In result, 36 of 1/3 solar cells made 9 voltage.


Instead of MPPT,
only small reverse current circuit breaker was installed.


Maiden flight was done. 3:00


But, test of solar cell effect was impossible
because it was PM 3:00 and cloudy.
At last of flight, it started to rain.


This 36 solar cells are twice of my first hybrid Drift 877
   • Hybrid conversion of Drift 877, solar cell...


So, I expect longer flight at next sunny day.


Thank you for watching ^^




Modification of Razor to pusher type
   • Razor of Eachine, Modification to pusher type


Maiden flight of Razor
   • Maiden flight of Razor modified to pusher ...


Test flight
   • Boring test flight of Razor to check effic...




Specification of Hybrid Razor modifided to pusher type


Wing span : 1200 mm
AUW including Li-ion 2S1P : 473 grams added about 130 grams
motor : T-motor F2203.5 kv 3500
Propeller : 6x45
ESC : Emax lightning S 25A
Servos : default of PNP
Fpv camera : Runcam split 3 nano at nose
Caddx ant at bottom
Video transmitter : Eachine Nano V3
FC : Matek F722 mini se
LRS : Crossfire nano receiver
GPS rx : Beitian 220
DVR : Eachine DVR
Battery : Li-ion 3500mah 2S1P,
Lionpack of ZOHD
