UML Communication Diagram
Автор: Ave Coders
Загружено: 2021-04-05
Просмотров: 48384
Ave Coders!
Similar to Sequence diagrams, Communication diagrams are sub-types of interaction diagrams and show how objects interact with each other.
Communication diagrams, or as they were called prior to UML2.0 - collaboration diagrams essentially are the extensions of object diagrams that show these objects along with the messages that objects send to each other.
#avecoders #communicationdiagram #uml
