How the Fluke ScopeMeter® 190 Series II Was Designed

http://bit.ly/2RQHb1x

In this video, get an in-depth view of what a Fluke ScopeMeter is and how Fluke Portable Oscilloscopes were redesigned as a response to customer requests.

As the first four-channel portable scope safety rated CAT III 1000 V / CAT IV 600 V, the Fluke ScopeMeter® 190-204 combines an unprecedented level of performance, ruggedness, and portability with 200 MHz bandwidth and real-time sampling rates up to 2.5 GS/s and 200 ps resolution to capture noise and other disturbances. This model feature deep memory up to 10,000 samples per channel; so you can examine very small parts of the waveform in detail, and it is IP-51 rated to withstand dust, drips, humidity, and wide temperature variations. Fluke ScopeMeter® test tools are hand-held battery operated, designed to meet the demands of field service professionals.

Two electrically isolated inputs
CAT III 1000 V / CAT IV 600 V safety rated
200 MHz bandwidth model
2.5 GS/s
Deep memory: 10,000 samples per channel waveform capture so you can zoom in on the details
Dedicated 5000 Count digital multimeter
Connect-and-View continuous auto-trigger, single shot, pulse width, and video triggering
ScopeRecord roll mode, capture waveform sample data for up to 48 hours
TrendPlot, trend measurement readings for up to 22 days
Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s)
IP-51 rated for dust and drip proof to withstand harsh environments

For more information about Fluke 190 Series Portable Oscilloscopes, visit the Fluke website here: http://bit.ly/2RQHb1x
