FX-R 3.0 Bi-xenon projector full installation steps explained (Fiat Punto Evo)

𝗬𝗼𝘂 𝗰𝗮𝗻 𝗯𝘂𝘆 𝘁𝗵𝗶𝘀 𝗴𝗿𝗲𝗮𝘁 𝘂𝗽𝗴𝗿𝗮𝗱𝗲 𝗸𝗶𝘁 𝗵𝗲𝗿𝗲:
https://retrofitlab.com/products/ahar...

𝗜𝗻𝘀𝘁𝗿𝘂𝗰𝘁𝗶𝗼𝗻𝘀:
0:02 After opening the headlight, remove the reflector
0:06 Mark the beam pattern on a wall to align the beam pattern of the FX-R projector later. Make sure you fix the reflector on a flat surface in a way that you can reproduce later to align the projector.
0:44 Mark the area to cut from the reflector and cut it with a dremel tool
1:17 Clean the reflector before you'll mount the projector
1:37 Prepare Bison Kombi Stick to pre-fix the FX-R projector
2:25 Switch on the bulb to align the projector correctly
2:37 When the beam pattern is aligned correctly, hold the projector for a few minutes, the heat of the projector will make the Kombi Stick become hard soon
3:00 Prepare JB weld to fix the projector permanently
3:20 Apply the JB wel to the projector and let it dry for 24 hours
4:10 Place the shroud on the projector. Not shown, but use a little JB weld to permanently set the shroud on the projector.
4:28 As you can see here the headlight lens insert hits the shroud, we had to reposition the projector higher and more backwards in the headlight unit.
5:10 This is the result after repositioning!

𝗔𝗱𝘃𝗮𝗻𝘁𝗮𝗴𝗲𝘀 𝗼𝗳 𝗮 𝗕𝗶-𝘅𝗲𝗻𝗼𝗻 𝗽𝗿𝗼𝗷𝗲𝗰𝘁𝗼𝗿 𝗿𝗲𝘁𝗿𝗼𝗳𝗶𝘁 𝗸𝗶𝘁:
• Much better light output
• Double high beam (xenon + halogen)
• No glare
• Lower energy consumption (35 watt instead of 55 watt)
• Luxury OEM look

𝗖𝗵𝗲𝗰𝗸 𝗼𝘂𝘁 𝗼𝘂𝗿 𝗻𝗲𝘄 𝗙𝗮𝗰𝗲𝗯𝗼𝗼𝗸 𝗴𝗿𝗼𝘂𝗽:
  / europeanheadlightcommunity

𝗙𝗶𝗻𝗱 𝘂𝘀 𝗼𝗻:
Facebook:   / retrofitlab
Messenger: https://www.m.me/Retrofitlab/
Instagram:   / retrofitlab.com_official
Our website: https://www.retrofitlab.com/

𝗢𝘂𝗿 𝗦𝘁𝗼𝗿𝘆:
Retrofitting refers to the addition of new technology or features to older systems. These days there are a lot of people who put a simple plug & play xenon kit in their halogen headlight housing in an attempt to improve night vision and looks of their vehicle. In fact they don’t realize that their headlight beams are often worse than before. Night vision achieves relatively little improvement on night vision because of a poor beam pattern, which increases the blinding of other road users. This is because their headlight housings are designed for halogen and not xenon.

A true Bi-Xenon projector update is now possible for your car. Such an upgrade will significantly improve your light output from 700-2100 lumens to 2800 and 3500 lumens, without blinding other traffic with glare from your headlight. Upgrade your headlight OEM style!

The latest high power Led bulbs will upgrade both the exterior and interior lighting system of your car. Led lighting is becoming more and more popular in the automotive market for obvious reasons. They have longer lifetime, use less energy and improve safety with their fast response time.

Do you have any questions? Do not hesitate to contact us, we are happy to help you out!

Good luck with your retrofit!

These products are not ECE-approved and must not be used on public roads in any exterior application. Use on public roads will invalidate both the operating license and insurance coverage.
