Schmitt Trigger Inverter Oscillator - Fun with Nand Gates and RC Networks
Автор: Gadget Reboot
Загружено: 2019-06-29
Просмотров: 4080
Taking a look at the difference between a normal and a Schmitt trigger logic gate input with scope traces, and how to calculate the frequency of a Schmitt trigger inverter oscillator based on the charge and discharge time of the resistor-capacitor network.
Putting the oscillator to use to generate odd pulse waveforms to blink LEDs in custom patterns and building up toward a sound effect generator, with future projects in mind.
Helpful resources:
http://www.ibiblio.org/kuphaldt/socra...
http://www.ibiblio.org/kuphaldt/socra...
http://mustcalculate.com/electronics/...
http://www.ti.com/lit/an/scea046/scea...
Patreon: / gadgetreboot
Pinterest: https://www.pinterest.ca/GadgetReboot
Twitter: @GadgetReboot / gadgetreboot
Background music from the Youtube music library:
A Rising Wave by Jeremy Blake
Ridge Racer by DivKid
