How to Connect FS-X6B to Wizard X220 via i-BUS - Help for Beginners

You can now support RCwithAdam (and gain special perks!) HERE: https://ko-fi.com/rcwithadam 🤗
Visit my website here: https://rcwithadam.com/ 💻
Are you REALLY confused about how to connect the Flysky FS-X6B receiver to the Eachine Wizard X220? So was I! In this video I'll show you how I made a functional connector cable using the (incorrect) cables that come with the receiver, and which ports to plug into for i-BUS (which is basically just a name for the type of language that the Receiver (Rx)/Flight Controller (FC)/ Transmitter (Tx) use to communicate).

Link to Seriously Pro Racing F3 Flight Controller (the flight controller that the Wizard uses) manual: http://seriouslypro.com/files/SPRacin...

Link to Flysky X6B manual: https://img.banggood.com/file/product...

For anyone else confused about this connector stuff, here's a great forum thread about "JST" connectors with very helpful pictures! https://www.rcgroups.com/forums/showt...
