Telewave TPRC-1505 Pass/Reject Cavity Tuning
Автор: Telewave-io
Загружено: 2017-08-28
Просмотров: 10727
How to tune a Telewave TPRC-1505 Pass/Reject Cavity.
Video Contents:
00:11 - TPRC-1505 Duplexer Introduction
01:07 - Pass, Coupling, and Reject Tuning
01:59 - Identifying a Duplexer's Current Tuning
02:41 - Adjust SPAN to 5 MHz for Better Resolution
03:10 - Set Markers to Desired Pass & Reject Frequencies
04:02 - Adjust Peak & Notch Using Center Screw & Piston Cap
05:55 - Check Return Loss & Tweak Notch, Pass & Return Loss
07:33 - Summary
Learn more at: https://www.telewave.com
For toll-free support, please call: 1-800-331-3396
For other inquiries: https://www.telewave.com/contact-us/
Additional Documentation for Field Tuning:
https://www.telewave.com/resources/fi...
