Robotic Pallet Nailing Demo Cell

Check out our Pallet Nailing & Stacking Robot!

In this robotic pallet building cell, we used an #ABB robot IRB6700 with IRC5 controller.
The custom-designed tooling was made with an automatic nailer and pallet handling capability.
This system includes a fixture that is manually adjusted to fit 1 of 3 pallet layouts with more layout options available.
We also incorporated a robust safety system complete with area scanners, light curtains, and safety fencing.

STATS:
48 seconds per pallet
45 nails per pallet
2.25”-3.5” long screw shank nails
.099-.150 gauge
Average pallet weight = 28.3lbs
Average operating pressure = 90psi

Contact #7robotics for more #robotics & #automatedsolutions!
7robotics.com | (541)236-7105 | info@7robotics.com
