The R-2R Ladder | Op-Amp Basics, episode 8
Автор: Kludges from Kevin's Cave
Загружено: 2025-06-27
Просмотров: 2193
Please help me in supporting Médecins Sans Frontières | Doctors without Borders
https://events.doctorswithoutborders....
In this episode, we design a simple D/A converter, correcting some of the faults of the direct converter that we saw in episode 2. We examine several things that can go wrong with it, especially resistor mismatch and clock skew.
All the circuits demonstrated are from previous episodes. Schematics are on the project GitHub, https://github.com/kennykb/kevins-cav... and https://github.com/kennykb/kevins-cav...
00:00 Intro
00:55 Why not direct conversion?
03:39 Public service announcement
05:20 The R-2R ladder
08:34 Nonlinearity / nonmonotonicity
09:11 Clock skew / ripple counting
12:44 Next steps
