Random Wire Endfed project with a 9:1 unun

Автор: 73outdoors w/ Bob KK4DIV

Загружено: 2021-09-03

Просмотров: 5411

Описание:

I have been wanting to find antenna wire that is lighter and less bulky than my current copper clad aluminum I use for my endfed. So on Sotabeams website, I purchased 45 meters of their DX-wire ultra-light antenna wire. Using a website I share in the video, I cut 2 lengths of this wire for portable radio applications.

/ bobplank

Music credits:
The Beacon by Zachariah Hickman

Camera equipment:
GoPro Hero 8 Black (while adventuring or outdoors)
Canon Vixia HF R800 (in the studio)

Editing software:
Corel Videostudio Ultimate 2018

My favorite radio equipment for outdoor portable ops or RaDAR:
Radio: Icom IC-705
Tuner: Elecraft T1 tuner
Antennas: Chameleon F-Loop magnetic loop antenna (does not need a tuner)
End fed antenna with 9:1 unun (needs tuner)
Sotabeams Bandhopper 20/30/40 linked dipole
Digital software: FLDigi and WSJT-x
