5 Watt Long Range Fm Transmitter And Working Principle
Автор: Et Discover
Загружено: 2019-04-28
Просмотров: 78983
JLCPCB Prototype for $2(Any Color): https://jlcpcb.com
Make sure to visit their website.
Schematic, PCB layout, GERBER Download link
https://ietdiscover.blogspot.com/2019...
COMPONENt
#1# condenser mic
#2# 3.5 mm socket
#3# CL1005 Transistor
#4# 4.7k Resistor
#5# 2.2k Resistor
#6# 10k Resistor
#7# 220Ohm Resistor
#8# 22pf ceramic capacitor
#9# 6.8 pf ceramic capacitor
#10# 102 ceramic capacitor
#11# 1uf electrolytic capacitor
#12# LED Yellow
#13# 30pf trimmer capacitor
#14# 100nf ceramic capacitor
