Ford Capri V8 Project Brake Upgrade Part 1
Автор: Eurostang
Загружено: 2015-11-05
Просмотров: 6233
Fitting 260mm disks to my Ford Capri with calipers from a '92 Granada Scorpio
Disks are 260mm in diameter, 24mm thick 58mm bell height 64mm centre bore. Part number 6169974. They was fitted to:
Escort RS turbo 86-90
Sierra 1.6, 1.8TD and 2.3D +abs 82-93
Sierra 2.0i +abs 85-93
Sierra XR4i 83-85
There are a couple of other viable options too
An identical disk, except 53mm height (oem 1638879) was fitted to XR4x4 sierras, and Mk3/4 escorts with abs have 240x24x58 disks.(oem 1644844) For 5 stud (granada) the nearest seems to be Mk3 granada scorpio non "cosworth" @ 260x24x53 (oem 6158214)
Using 53mm disks will require 5mm longer spacers between hub and caliper and may reduce your wheel choice (depending on caliper choice).
