Which Is The Best Type Of Standing Seam Metal Roof? Snaplock Vs Mechanically Seamed Vs Nail Strip

There are three different types of standing seam metal roofing panels. All of these different panel types have there own sets of pros and cons. By the end of the video you will know which types of metal roofing is best for you.

00:00 Types of metal roofing
00:40 Types of standing seam metal roofs
01:05 What is snap lock metal roofing?
01:56 What is mechanically seamed metal roofing?
03:04 What is nail strip metal roofing?
04:27 Which style of metal roofing is best?

If you already have not purchased your metal roofing give us a chance to bid your job. Save 15% to 50% with our manufacturer direct pricing and great customer service. Inexpensive delivery anywhere within the United States.

Visit Our WEBSITE
https://bit.ly/wsmr-website

Visit our LEARNING CENTER
http://bit.ly/learning-center-wsmr

Snap Lock Standing Seam Metal Roofing Panels
https://www.westernstatesmetalroofing...

Mechanically Seamed Roofing Panels
https://www.westernstatesmetalroofing...

Nail Strip Standing Seam Roofing
https://www.westernstatesmetalroofing...

Standing Seam Metal Roofing Installation Series
   • Standing Seam Metal Roof Installation: Ste...

Types Of Standing Seam Metal Roofing: Pros And Cons
When you are searching for the best standing seam roof panel? While the decision to use standing seam might be an easy one, which type of standing seam metal roofing to use may require a bit more consideration.

There are three different types of standing seam metal panels to choose from, along with different types of stiffening ribs or striations that can be included within them.

What Is A Standing Seam Metal Roof?
Standing seam metal roofing is sheet metal that has a flat appearance that has a flat appearance in the center and vertical ribs at the panel edges. It’s the most weather-tight metal roofing system because it’s attached with concealed fasteners.

What Are The Types Of Standing Seam Metal Roof Panels?
These are three types of standing seam roof systems:

Snap Lock
Mechanically Seamed
Nail Strip/ Nail Flange

Snap Lock Roofing With Clips
The snap lock standing seam roof system consists of panels with a male and female leg that snap together. These panels are fastened to the roof with clips, and the fasteners are concealed.

Snap lock standing seam is the most common type of standing seam roofing. Its popularity comes from being regarded as the best all-around standing seam solution when you consider the performance of the panel, cost, and easier installation than some of the other standing seam panels.

Mechanically Seamed Metal Roofing
Mechanically seamed panels are designed with clips that line up with one another to be locked together by a mechanical or hand seamer.

Mechanically Fastened Metal Roofing: Single Lock Vs. Double Lock
Mechanically seamed panels can either use a single lock system or a double lock system when they are seamed together.

A single lock refers to the seams of the panel being folded once (90 degrees) and a double lock is when the seams of the panel are folded twice (180 degrees).
Double lock systems are more commonly used. They are more secure and have an overall better performance over a single lock system.

Nail Strip Standing Seam Roofing
Nail strip, also known as nail flange or fastener flange, is the snap lock standing seam roof system with the simplest installation process. The male flange has one-inch slots that are spaced 6 inches apart and fastened directly to the roof deck, eliminating the need for clips. Once the panel is fastened, the female leg of the panel snaps over, hiding the fasteners.

Nail strip panels are used most often for residential standing seam roofing jobs because they’re the least expensive standing seam system. However, this panel has the worst performance of the three types of standing seam panels.
