How To: Boardnamics AT Gear Drive Teardown & Assembly

In this video, I do a teardown and assembly of the new Boardnamics AT Gear drive. I've got these attached to Matrix II Oil Slick trucks, with 6384 Flipsky motors. With Matrix II Oil Slicks, the coating on the truck can be problematic for press-fit accessories like this drive. I had to remove a decent bit of the coating around the ends of the truck hangers but was able to press the mount adapters on in the end.

Out of four matrix 2 trucks, only one was able to barely fit the adapters on without modification. However, on black Matrix II trucks, the fit should be perfect.

The gear ratio that I've got in this video is the highest one, with a 16T motor pinion, and the 83T drive gear. This configuration offers the highest amount of torque.

If you have any questions whatsoever, feel free to reach out to me or post in the comments. These aren't too hard to assemble, but the less mistakes, the better!

You can purchase these gear drives on the Boardnamics website in either a fully assembled state, or in pieces like I got mine.
Find drives here: https://boardnamics.com/

This video has a good bit of explanation in it, so feel free to use the timestamps to find exactly what you need. The re-assembly starts at 4:45.

Timestamps:
0:00​​ Introduction
0:49​ Wheel Removal
1:45​​ Wheel Adapter Removal
1:57​​ Outer Case Removal
2:57 Drive Gear Removal
3:50​​ Other Disassembly Steps
4:18 Oil Slicks Information
4:45​ Attaching Plate & Adapter
5:44​ Attach Motor
6:20​ Loctite Motor Screws
6:45​ Attach Motor Pinion
8:52​ Attach Drive Gear
9:10​ Adjust Backlash
9:31​ Attach Outer Case
10:40 Attach Wheel Adapter
11:17 Wheel Preparation
13:15​ Wheel Attached
13:52​ Outro
