OpenSource CFD Hands on Tutorial | Damper Simulation using OpenFOAM | enGrid Mesh Generator

Disclaimer:
enGrid is being developed and maintained by enGits GmbH.

enGrid is licensed under GPL version 3.0 http://www.gnu.org/licenses
-------------------------------------------------------

OpenFOAM® and OpenCFD® are registered trademarks of OpenCFD Limited, the producer of the OpenFOAM software. All registered trademarks are property of their respective owners.
-------------------------------------------------------
ParaView uses a permissive BSD license that enables the broadest possible audience, including commercial organizations, to use the software, royalty free, for most purposes. It is being developed and maintained by Kitware Inc. Sandia National Laboratories. All registered trademarks are property of their respective owners.
-------------------------------------------------------
This is the third tutorial of the Opensource CFD hands on tutorial series.

How to mesh a damper enclosed within a duct using an excellent opensource mesh generator i.e. enGrid

. Extract fluid volume and export mesh in OpenFOAM format

. Turbulent flow modelling using incompressible OpenFOAM solver i.e. simpleFoam
-------------------------------------------------------------------------------
enGrid is an open-source mesh generation software with CFD applications in mind. enGrid uses the NETGEN library for tetrahedral grid generation and an in-house development for prismatic boundary layer grids. Internally, enGrid uses the VTK data structures as well as the *.vtu file format.
enGrid is released under the GPL and we hope that it is a useful addition to the open-source CFD community.
---------------------------------------------------------------------------------
enGrid Download link:
https://sourceforge.net/projects/blue...
For Windows:
enGrid_1.5.0-dev_setup_win64_MSVC2008_20131201.exe
-----------------------------------------------------------------------------------
OpenFOAM:
https://openfoam.org/download/
Used Version: OpenFOAM-8
Using windows sub-system for Linux
Ubuntu 20.04.3 LTS (GNU/Linux 4.4.0-19041-Microsoft x86_64)
------------------------------------------------------------------------------------

#cfd #meshing #openfoam
