eBay atomiser module test (with schematic)
Автор: bigclivedotcom
Загружено: 2022-01-31
Просмотров: 89717
A look at a very common little atomiser module sold on eBay. This style of circuit is often found in the USB powered desktop humidifiers that use a wick and piezo disk to put a visual stream of moisture into the air.
This is a very minimalist circuit, which makes it very interesting. There's no feedback, so the microcontroller is just banging out a rough 110kHz to the 16mm piezo disk.
I really went to town on reverse engineering this module, including desoldering and measuring all the capacitors, and unwinding the little transformer to count the windings and measure the wire diameter.
To find these on eBay search for - usb humidifier module
It's often cheaper to buy a multipack, plus that gives you spares.
