HOW TO DRAIN YOUR HEATING SYSTEM - Pressurised - PLUMBING TIPS

This video covers the basics of draining down your heating system to fix leaks, change radiators and move boilers etc. It covers isolating the water supply, venting the system, how to find your drain offs and radiator drop down legs, re filling the system, venting of air and inhibiting.


🛠AMAZON TOOL STORE: http://www.amazon.co.uk/shop/plumberp...
🥾10% Off my workboots + workwear Use Plumberparts10: https://www.bigboots.co.uk/discount/p...
👓10% Off Safestyle Sunglasses Use PLUMBER10: https://safestyle.com.au/?ref=PLUMBER10

THE TOOLS I USE

Main Tool Bag (Veto Pro Pack): https://amzn.to/2QhEOaV
Big Tool Bag for 'Long Tools': https://amzn.to/2TD3ycn
THE BEST Soldering Bag you could ever want: https://amzn.to/2OZimie
The BEST tape measure you're ever going to have! 10m OX: https://amzn.to/2DVLu99
Wide Jaw Adjustable Bahco Spanner: https://amzn.to/2TD3TvF
Bahco Adjustable set (has the 6 inch mini life saver!): https://amzn.to/2DThYk6
IRWIN Vise-Grip beasts great for pump valves and everything else: https://amzn.to/2OWdiLz
My Beloved Wera Screwdrivers (Metal ended): https://amzn.to/2TBoRv7
Wera Allen Keys Multi Coloured: https://amzn.to/2R9t0EM
EXCELLENT Bahco Socket set - fits in the bag and also on impact drivers: https://amzn.to/2R5Xqrx
Wire Strippers: https://amzn.to/2POsLSV
Rothenburger Plastic Pipe Cutters 15-50mm+: https://amzn.to/2DV9tVT
15mm PipeSlice: https://amzn.to/2R9KOj5
22mm PipeSlice: https://amzn.to/2Qeilvj
28mm PipeSlice: https://amzn.to/2DTNaQs
Mini Pipeslice (Good for 10mm etc): https://amzn.to/2OZh8n8
The Best Blowtorch ever made: https://amzn.to/2DTw5pC
The Gas (Hotter than Butane but you'll get used to it!): https://amzn.to/2PQr8UU
Solder Heat Pad: https://amzn.to/2BsGNkB
SHINY PIPES BRASSO: https://amzn.to/2BsILBv
THE BEST PIPEBENDERS EVER (Hilmor): https://amzn.to/2DTWlA6
My Main Hammer: https://amzn.to/2BtWBDA
Ox Mini Hammer/FloorBoard puller (Believe me this is a must!): https://amzn.to/2DUkExZ
PlumbTub (Great for radiator drain down and anything you need to catch water): https://amzn.to/2DEpePY
MagnoGrip Wrist Band - A must if you hate dropping screws/bits/tools: https://amzn.to/2R8gaa3
Epic Glove Torch great for servicing and fault finding: https://amzn.to/2BsjgQQ


**WEBSITE**
http://www.plumberparts.co.uk

This switch here turns it off, alright? That's the heating system off. We don't want it coming on or anything like that while we're draining down. The last thing we want is the boiler lighting up, or the pump coming on. It could burn the pump out, it could overheat the boiler and crack the sections. So the first thing you do is make sure that the heating system is switched off. "Ah, but James," I hear you ask in your stupid voice. "How does that pressurised heating system work?" "Well, y'know, I need a basic knowledge of them to know how to drain one down." Well, usually, you've got your boiler, your pump, any valves: you could either have a three-port valve there or a couple of two-ports. In this system, we've got two two-port valves.

Then you're going have your coil going into your cylinder, if you've got one; if not, a combi system. Then also you're going have your radiators, blah, back to the boiler, blah, back to the boiler. Now, some heating systems use a gravity feed in the loft to actually push water down, via gravity, from a tank up there with a ball valve in it down into the system. But nah, we don't have that on a pressurised system. 'Cos we ledges, aren't we? Yeah. Basically we have a cold water main come in, comes in, goes through a filling loop into what we call the manifold that's often at the bottom of the expansion vessel, So we've a big expansion vessel like that. So you got that, filling loop, braided hose. You have a non-return valve there, a valve there. This braided hose is removable, so the system doesn't automatically or accidentally fill up off the cold water main, which could pressurise it, which could bulge radiators, which could cause your whole world to come falling down. So yeah, there we go. That's the basic gist of how they work.

The water heats up, expands into this expansion vessel. Like I said already, go to our video on pressurised systems. So, let's have a look at this system here. So here's the loft that we're looking at and the particular part we're going be taking notice of is that bit there. So here we are on the lines down of possibly, possibly the worst pressurised heating system install I've ever seen. Right, so, we've got our feed from the cold main here. That's this valve here, we've got our braided hose here, that's also got a little valve in it that you can't see, but it's just a little black-handled valve. Let's get round here and have a little look. Can you see that? There it is. Now that braided hose comes up here and through this, which is a non-return valve,
