Spring loaded bit | PCB solder mask milling | CNC3018
Автор: diy_projectx
Загружено: 2022-01-29
Просмотров: 5164
DIY cnc cnc3018 3018 pcb milling routing printed circuit boards prototyping solder mask milling
****************************************************************************
**if you like this please give me a thumbs up or a feedback down below in the comments. Thanks.**
****************************************************************************
Thingiverse-Link: https://www.thingiverse.com/thing:526...
How-To:
for milling solder mask off a custom PCB you have to spring-load your engraving bit. So the pressure is high enought to mill the solder mask (UV-resin) off the PCB- but not strong enought to mill trought copper.
You need:
ER11 nut
spring from ballpoint pen
3-d-printed holder and connection
90 degree engraving bit
For questions please write a comment. I will answer as soon as possible.
If you need CAD-files please feel free to ask.
********************************************************************
Music: https://www.bensound.com
