Pfaudler 20 GAL Full Jacketed Glass Lined Reactor Demonstration

To view additional machinery on our website click here: http://www.fraingroup.com/equipment-c...

Pfaudler, 20 gallon, full jacketed, glass lined reactor. Gallons of product per hour - depending on materials, application and machine configuration. Equipped with bolt down dome top, (1) 4" diameter sight glass, glass baffle and top mounted glass lined prop style agitation powered by a 3 hp drive. Dish bottom has a 2"OD / 1½"ID Tri-Clamp style center bottom discharge with 12" floor clearance Mounted on (3) tubular bolt down legs.

Top Ports:
(1) 2½"OD / 2"ID - Tri-Clamp
(2) 2"OD / 1½"ID - Tri-Clamp

Jacket Ports:
(2) 1¾" NPT
(2) 1½" NPT
(1) ½" NPT

MAWP: 150/FV PSI @ 450°F (Vessel)
MDMT: -20°F @ 150 PSI (Vessel)
MAWP: 125 PSI @ 450°F (Jacket)
MDMT: -20°F @ 125 PSI (Jacket)
Nat'l Brd: 51355

OAD: 36" L x 30" W x 67" H
