Turning a Scrap Sony Trinitron CRT into an Awesome 240p RGB Gaming CRT
Автор: SpudzOldGameZ
Загружено: 2021-10-31
Просмотров: 55226
In this Video i go in search of a scrap CRT i can turn into an awesome 240p RGB gaming CRT for all the older consoles. The Deatils of this video below
TV Model: Sony KV-T29SZ8
Service Manual:
https://www.manualscenter.com/manuals...
Jungle IC: TDA8375A
https://datasheetspdf.com/pdf-file/32...
Parts I Used.
Toggle Switch:
https://www.jaycar.com.au/spdt-sub-mi...
RCA's (Red link shown below, Blue and Green can also be found by searching)
https://www.jaycar.com.au/gold-rca-so...
90 Degree RCA Adapter (If required)
https://www.jaycar.com.au/rca-right-a...
You will Also Need:
3 x 150r Resistors to go in the RGB lines in Series. (Note in this Video i used 75R resistors to Ground which will also work
Solder, Cable, 8mm Dril bit (For RCA'S), 6mm Drill bit (For Toggle)
