1949 Norton Model 30 International

1949 Norton Model 30 International

The chase all the way to the UK and back. The Story of this 1949 Norton Model 30 International

This interesting machine was raced by the late Ian Paskin of Birmingham, a former Norton works engineer and a competitive rider in grass track, speedway and road racing.

The Norton International 500 or Cammy Norton is a Norton Motors Ltd overhead cam (OHC) motorcycle built between 1931 and 1957.

More than a TT replica sports roadster, the OHC Model 30, was 500 cc and the OHC Model 40 was 350 cc. During the 1930s it could be ordered from the Norton factory with all manner of racing parts fitted. Such factory bikes won many Isle of Man TT races during the 1930s, many of them 1-2-3 results.

The name International was first used by Norton both for its newly designed race bikes and also for the TT replica sports roadster in 1932. Overseen by Joe Craig, Arthur Carroll had designed an overhead-camshaft engine for the works racers and although it retained the 79 mm × 100 mm (3.1 in × 3.9 in) bore and stroke of the Norton CS1 the Model 30 International was all new. The racing heritage led to quickly detachable wheels and hairpin type valve springs that could be changed rapidly when racing. In 1933, the forks and gearbox were redesigned and in 1935, the Sturmey-Archer gearbox was replaced, as Sturmey-Archer had stopped making gearboxes, so Norton bought the rights to the design and commissioned Burman to produce them. These gearboxes proved so good they remained unchanged for the next 30 years, although the external appearance was altered several times, and the gearchange mechanism fully enclosed and thus lubricated.

In 1936, the engine was upgraded with an alloy head and barrel with a bronze liner, available as an option. In 1938 suspension was upgraded to plunger type. And telescopic Roadholder Forks as ridden by Harrold Dannels and Freddie Frith in this year 1938 also available as an option. Production of the Model 30 and 40 ended on the outbreak of World War II.] After the war, production of the International Model 30 (500 cc) and Model 40 (350 cc) restarted with an iron head and barrel, as fitted to the pre-war CS1 and CJ Nortons. The suspension was upgraded to Norton Roadholder telescopic forks instead of girders and Clubmans versions were also produced without silencers and lights for racing use. Close ratios gearboxes were supplied as standard from 1947, and the alloy-headed engine made a comeback in 1953 in the new Featherbed frame. Volume production of the International ended in 1955, although small numbers were built to special order for two or three years after.[1]
