ISAI Vacuum Casting Machine (8kW) | Made in Japan |
Автор: CASCADE STAR
Загружено: 2026-01-06
Просмотров: 14
Introducing the ISAI Vacuum Casting Machine by Eishin Technology Co. Ltd., Japan — a high-performance casting solution engineered for modern jewelry manufacturing. 🇯🇵💎
This 8kW vacuum casting machine is designed for high efficiency, precision, and consistent casting results. With advanced PID auto tuning, compact design, and fully or semi-automated operation, the ISAI casting machine delivers reliable performance for professional jewelry manufacturers.
🔹 Key Features:
• PID auto tuning for precise temperature control
• Seal & lock flange – no need for traditional flange
• Full Auto Mode & Semi-Auto Mode
• 3 gas ports (inert gas, pressure gas, actuator driving device)
• Pressure gas & actuator driving device can be used separately
• Optimized inert gas consumption
🔧 Technical Specifications:
• Power Supply: Three Phase AC 200–220V ±10%, 50/60Hz
• Power Consumption: 8.0kW / 9.5kVA
• Temperature Range:
– K-Type: up to 1200°C
– R-Type: up to 1400°C
• Crucible Capacity:
– K18: 2.3kg
– K14: 2.4kg
– Ag925: 1.5kg
• Flask Size: Ø75–130mm | H 90–250mm
• Cooling Water: 10–30°C | Pressure 0.15MPa | Flow 3L/min
• Gas: Inert gas (Argon, etc.)
• Max Pressure: 300kPa
• Machine Size: 740(W) × 700(D) × 1590(H) mm
• Weight: Approx. 250kg
🏭 About Cascadestar India:
Cascadestar is a trusted distributor of advanced machinery for the jewelry industry, offering cutting-edge technology from global leaders along with expert support and service.
📩 For inquiries, demos & pricing:
🌐 Website: https://cascadestar.in
📧 Email: info@cascadestar.in
👍 Like | Share | Subscribe to Cascadestar India for more jewelry machinery demos and industry solutions.
#CascadestarIndia #ISAI #CastingMachine #JewelryCasting #EishinTechnology #MadeInJapan #VacuumCasting #JewelryMachinery
