How to build a REAMP box and WHY you need one

What is a reamp box, why would you use one and how to build it for about 20$.


Schematics:

https://ibb.co/BPwvDnS

Parts list:

Box: Hammond 1550A or any metal box bigger than 89x35x30mm
https://si.farnell.com/hammond/1550a/...

XLR Connector: Neutrik NC3FAV1 (any XLR connector will work)
https://si.farnell.com/neutrik/nc3fav...

Jack Connector: Any two contact mono jack in plastic housing (like Neutrik NMJ4HF-S)
https://si.farnell.com/neutrik/nmj4hf...

Transformer: VTX-101-1604 (or any 600:600ohm line level audio transformer)
https://si.farnell.com/vigortronix/vt...

Resistor: 10kOhm (250mW power rating is enough)
https://si.farnell.com/multicomp/mcf-...

Potentiometer: 100kOhm Logarithmic
https://si.farnell.com/tt-electronics...

Switch: SPST or SPDT toggle switch
https://si.farnell.com/multicomp/1ms1...

Knob: 6mm round shaft knob (any 6mm knob will work - it's best to keep the diameter at 16mm or less)
https://www.tube-town.net/ttstore/cla...



You can find these components on other sites as well, often cheaper.

-----------------------------------------------------------------------------------------------------------

Software for frequency and distortion analysis:

RoomEQWizard: https://www.roomeqwizard.com/

-----------------------------------------------------------------------------------------------------------
