DIY Solar automatic transfer switch

DIY Solar automatic transfer switch. An automatic transfer switch (ATS) is a device that allows for a seamless transfer from grid power to solar power without any disruption of service to the connected load¹. A solar ATS is an important component for grid-tied solar projects, and it is often referred to as a solar intertie switch².

A solar ATS can monitor both sources, and connect to the alternate source whenever necessary – without requiring manual operation³. It can also prevent power from feeding back to the grid, which could cause danger to utility crews. A solar ATS can be used with different types of solar systems, such as grid-tie, off-grid, or RV solar systems.

make gpio swicth esphome    • gpio switch esphome home assistant
install home assistant
on windows    • how to Install Home Assistant 11.1 on Wind...
on STB Android    • tutorial install home Assistant on STB and...
esphome flasher    • espflash flasher esphome home assistant

automation home assistant
--------------------------------------------------
alias: 2. ATS Off 25.5 volt
description: "25.5"
trigger:
platform: numeric_state
entity_id: sensor.tegangan_baterai1
for:
hours: 0
minutes: 1
seconds: 0
below: 25.5
condition: []
action:
service: tts.google_translate_say
data:
entity_id: media_player.dapur
message: "ATS OFF. Beban Dipindahkan ke PLN "
type: turn_off
device_id: e14af0aa285f9e31f6c40d24852305ab
entity_id: c3483ec1f8dedc8a0a83b397fc274293
domain: switch
type: turn_off
device_id: e14af0aa285f9e31f6c40d24852305ab
entity_id: efcc015096d28dee28f26bd0418b81b6
domain: switch
mode: single
------------------------------------------
alias: "ATS ON "
description: "25.8 volt menyala "
trigger:
platform: numeric_state
entity_id: sensor.tegangan_baterai
for:
hours: 0
minutes: 1
seconds: 0
above: 25.8
platform: numeric_state
entity_id: sensor.tegangan_baterai
for:
hours: 0
minutes: 1
seconds: 0
above: 26
condition: []
action:
type: turn_on
device_id: e14af0aa285f9e31f6c40d24852305ab
entity_id: c3483ec1f8dedc8a0a83b397fc274293
domain: switch
type: turn_on
device_id: e14af0aa285f9e31f6c40d24852305ab
entity_id: efcc015096d28dee28f26bd0418b81b6
domain: switch
mode: single
-----------------------------------------

#diy #solar #automatictransferswitch https://katalogproduk.co.id/achmadcho... barang-barang yang saya beli di shopee untuk konten
