How to use the Arducam Mega (B0400) with the Arduino Uno

In this guide, we will show you step-by-step how to set up the Arducam Mega 3MP Camera - B0400 using Arduino Uno.

------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Step 1.
Installing the Arduino Software - https://www.arduino.cc/en/software

Step 2.
Downloading the Arducam Mega Libraries - https://github.com/ArduCAM/Arducam_Mega

Step 3.
Installing the Arducam Mega GUI tool - https://github.com/ArduCAM/Arducam_Me...

Step 4.
Use the Arducam Mega Library and open the Arduino Uno example "full_featured".

Step 5.
Check that the COM port and Board are connected to the Uno.

Now you should be able to upload the script and run the Arducam Mega GUI tool to output your camera feed.

Use these links for some more relevant and helpful pages.

https://www.arducam.com/docs/arducam-...
https://docs.arducam.com/Arduino-SPI-...

------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Interested in understanding more about embedded vision and Arducam products? You can't figure out how to set up your Arducam Camera, or you don't know the relevant commands?

Keep an eye out for future video guides and relevant technology information by subscribing.

------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Products used in this video:

Arducam Mega 3MP SPI Camera Module
Product Code: B0400
https://shop.scorpion.vision/collecti...

You can find us on our social media:

LinkedIn:   / scorpion-vision-ltd
Instagram: @scorpionvision_ -   / scorpionvision_
Twitter: @ScorpionVisUK -   / scorpionvisuk
Facebook:   / scorpionvisionltd

Or contact us at:

Sales@scorpion.vision

#howto #setup #guide #tutorial #camera #arduino #arducam #embedded_systems

00:00 Unboxing
01:02 Connecting the camera
01:15 Connecting wires to Arduino
01:49 Step 1
02:08 Step 2
02:22 Step 3
02:58 Step 4
03:24 Step 5
04:00 Camera Preview
05:18 Outro
