TBC vs Civil 3D - Survey-Setup Point Codes - Description Keys in Civil 3D

The setup process for integrating field-to-finish workflows in Business Center and Civil 3D involves configuring description key sets and point styles. In Civil 3D, description key sets control how points, represented as symbols, are displayed. Users can create new description keys by naming them and associating codes like 'CP' to identify control points. In Business Center, a similar process involves creating a new point feature definition, assigning it a name and code, and categorizing it. The symbol for the control point is added by selecting from a symbol library or importing from AutoCAD files. In Civil 3D, point styles are defined by selecting markers, setting layers, and configuring attributes like size and rotation. The description key set is tied to a drawing template, while in Business Center, it is separate and can be imported anytime. Label styles in Civil 3D determine what information is displayed, such as northing and easting. Parameters can be set to scale or rotate points based on codes entered by the crew. The setup ensures consistency between Business Center and Civil 3D, facilitating efficient project management. The next step involves setting up line codes for both platforms.
