Transfer Case Bearings and Seals - 100 Series Land Cruiser/LX470

Howdy! In this video I describe the process needed to replace your transfer case bearings and seals on your 100 series Land Cruiser and LX470. This job, while intensive, is not hard. Hopefully this video helps motivate you to tackle this job! If you have any questions or issues, please feel free to reach out.

Parts needed:
Front Seal: 90311-50014
Front Bearing: 90363-40083
Rear Seal: 90311-58008
Rear Bearing: 90363-50005
FIPG: 00295-01281

** A great “while you’re in there” item not noted in the video would be to lubricate the transfer case linkage. This commonly freezes on trucks that never went into 4Lo in their previous ownership, and you won’t get any better access to the linkage with the whole transfer case out! **

Steps:
00:00 - Intro
01:38 - Removal of Driveshafts
03:46 - Removal of Harness/Linkage/Breather
07:46 - Removal of Transfer Case from Vehicle
10:11 - Removal of Front Transfer Case Housing
12:20 - Disassembly of Front Transfer Case Housing
17:37 - Reassembly of Front Transfer Case Housing
24:49 - Reinstallation of Front Transfer Case Housing
26:44 - Removal of Rear Transfer Case Housing
27:44 - Disassembly of Rear Transfer Case Housing
30:11 - Reassembly of Rear Transfer Case Housing
31:56 - Reinstallation of Rear Transfer Case Housing
32:56 - Reinstallation of Transfer Case on Vehicle
34:42 - Reinstallation of Driveshafts
