Setting up Flaps - FrSky ETHOS Tutorial Series

This is a long video. However, if you just want to learn how to do the popular flaps setup with flight modes for elevator trim, that section is only 10 minutes long. I do however offer an alternative.

My method does Not use flight modes. I use a mix which solves a few issues when using slow downs and flight modes.

The flight mode method (which I call the Simple Flap setup) works very well and many people use it with success. I do demonstrate a few weaknesses with this setup. But if you want a different approach to setting up flaps, I show you my method. There two versions of my method. One with a switch controlling the flaps and one with a slider controlling the flaps.

After the video was completed, I decided to add one more section. I originally demonstrated my method for a Flap to Elevator mix to add some elevator compensation when engaging the flaps. I personally never do aileron compensation but I'm sure that many do. I added a section that shows how to set that up. It's essentially the same process as the flap to elevator mix but I thought it would be good to show it.

At the end of the video, I also added a section on using the Balance Channels feature (or servo matching) do you can fine tune your flaps so they move exactly the same throughout the range of motion.

Visit the ETHOS website at https://ethos.frsky-rc.com​

Visit the FrSky website at https://www.frsky-rc.com/

Chapters:
00:00 Introduction
00:37 Typical Flap Setup and the Problems
04:24 How to Build Simple Flaps
15:01 My Flap Method (Demo)
16:53 Build The Flaps (Switch Version)
31:54 Build The Flaps (Slider Version)
51:58 Add an Aileron to Flap Trim (Switch or Slider)
01:02:02 Balance Channels
01:10:56 Thanks and Goodbye
