New Gib Plate for a Compound
Автор: ChrisB257
Загружено: 2015-08-18
Просмотров: 5755
NOTE - just found comment notifications are not coming in so - late to see them, thanks to all.
We were asked to investigate a potentially problematic compound slide. It appeared that however gib screws were taken up, there was lateral 'slop' on its top slide - not good for machining consistency. Inspection found that the existing gib plate was not uniform in thickness, being significantly thicker in the middle section so, it was decided to make a new one from scratch. New and better gib screws should finally improve adjustability plus adding lock nuts.
The link for a demo video (we referred to at end the video) on the Acute Tool Sharpening System by Eccentric Engineering is here on The old Man's Shop page - http://www.oldmansshop.com/misc-vid-p...
( www.oldmansshop.com/ )
