Understanding Mechanics of Materials-Shear-Unsymmetric loading, Shear Centre
Автор: Abir Ghosh
Загружено: 2026-01-13
Просмотров: 7
Chapter 5, Shear
Session 40:- Unsymmetric loading
of thin-walled members, Shear Centre
For other videos- • Understanding Mechanics of Materials
We discuss unsymmetric loading cases, first for members with one axis of symmetry and then for members with no axis of symmetry. We first consider a channel section and discuss the way loading at the shear centre perpendicular to the axis of symmetry is similar to applying a load at the centroid of a rectangular section of a beam. In the first case there is no torque and in the second case there is no moment in the section. Applying a load at a different point causes additional torque in a channel section and moment in a beam of rectangular section. We next discuss cases, where there is no axis of symmetry. Thus the case of an unequal angle and a z-section is deliberated upon.
For video before:- • Видео
For video after:- • Видео
