Sansui 310 tuner amplifier
Автор: Bayu Solo
Загружено: 2010-10-21
Просмотров: 4644
see also in http://www.flickr.com/photos/saka_mat...
Sansui Stereo tuner amplifier Solid State 310.
Specifications
Year 1972
System: Transistor Receiver
Colour: 1=Silver, 2=Black: 1, 2
Pre Amplifier
Inputs: 1 Phono (mag.I); 1 Tape; 1 AUX; 1 Monitor
Inp. Sensitivity High Level: 180 mV
Inp. Impedance High Level: 100 kΩ
Inp. Sensitivity Phono MM: 3 mV
Inp. Impedance Phono MM: 50 kΩ
Power Amplifier
Speaker Outputs: 2 x 2 Speakers; Phones
Continuous power 8Ω: 15 + 15 Watts
Dynamic Power 8Ω: 18 + 18 Watts
Frequency Response: 30-35,000 (± 1 dB) HZ
Harmonic Distortion: 0.4 % at rated output
Tuner
Display: analog
Frequency Range FM: 88-108 MHz
Frequency Range AM: 535-1,605 KHz
Dimensions in Inches: 17.12 x 4.92 x 11.02 (w) x (h) x (d)
Dimensions in mm: 435 x 125 x 280 (w) x (h) x (d)
Weight in lbs: 16.75 lbs
Weight in Kg: 7.6 Kg
