Ethernet/IP Communication TM251 (Master) with FX5-ENET/IP (Slave)
Автор: Automation Engineer ID
Загружено: 2024-02-06
Просмотров: 2217
This video contains information about how make data communication between Schneider PLC (TM251 as Master) with Mitsubishi PLC (FX5U + FX5-ENET/IP as Slave) using Ethernet/IP Connection.
▬ Contents of this video ▬▬▬▬▬▬▬▬▬▬
00:00 – Opening
00:15 – Configuration
00:22 – Download FX5-ENET/IP EDS File
01:54 – Setting TM251 as Master
05:01 – Setting IP Address FX5-ENET/IP
06:41 – Setting FX5-ENET/IP as Slave
07:50 – Programming Communication (GX Works3)
12:07 – Test Device Connection
12:40 – Check I/O EtherNet/IP
14:37 – Closing
