See how to align the wheels on your UTV or ATV in this video from Partzilla.com.

When you’re aligning the wheels on an ATV or UTV, what you’re really doing is comparing two measurements: a line right to left across the ATV at the front of the tire and again at the back of the tire and then comparing. If the front measurement is lower, the wheels are toe-in. If the front measurement is larger, toe-out. And if they’re the same? The wheels are parallel.

Is toe-in or toe-out better on an ATV or UTV? It depends on what you’re after. If the wheels are toed in slightly, it will help with bite when you corner. A slight toe-out will offer stability at high speeds.

We’re back working on our YXZ1000R, and for this job we’re going to introduce you to an alignment tool to help you get accurate measurements for your alignment as well as your camber. John will show you how to get the High Lifter alignment tool installed on your wheels and then he’ll show you how your measurements will differ depending on if your front suspension has a load on it or if you have it lifted off the ground.
