MyFlyDream Crossbow Mini MavEmu TBS GPS PUCK

This was a test to confirm mavemu works with the tbs puck and corepro. No flight controller was involved. Set tracker protocol to Alt_Gps. Bluetooth hc05 set to 57600 baudrate, tracker port baudrate also set to 57600. I set full size crossfire bluetooth to mavemu. I powered on and bound to the crossfire diversity rx full size. I discovered sensors. I left the sensors in metric. It would likely still work if you change your sensors to standard. Let the gps puck obtain 6 sats. I set home position. Forgot I didnt calibrate, so i went and set compass to only on power up. Then powered it off and back on with it facing relatively north. I went into compass calibration and hit calibrate. Then spun the entire tracker clockwise until the countdown stopped. Had a pile of metal next to me, so compass was bouncing a bit. Moved the entire tracker over and turned it until the screen read between 359-001. Then I hit the right button on the tracker and set home again. Sat count was bouncing between 4-7 sattelites. Had overcast and high voltage lines on the other side of the tree.


Picked up the rx and gps and took a walk. Tracker started moving before I hit the minimum distance. I attribute that to the low sattelite count. Walked through my neighbors yard and the tracker pointed right at me when minimum distance was met. Then I walked around the neighbor's and watching the video it tracked me fairly close. Then I walk passed it and around the other side of my house. Again the tracker followed fairly decent. Considering I walked under my deck and a few trees. Then I walked to the back corner of my yard after I passed the tracker again. Being under heavy tree cover blocked my lock.

I came back and stopped the camera. Then thought crap. Need to see if it will continue to track after losing telemetry. Powered off my remote and lost dlink. Powered my transmitter back on and took a walk. Dlink had to of came back because the tracker spun and locked onto me again once I got across my neighbors lawn.
