Bargain logic analyzers: setup, teardown and comparisons.

A rabbit hole of logic analyzers... that's what I’ve been down in the last couple of weeks!!

I recently bought a cheap logic analyzer from Aliexpress and was super impressed with its performance. I made a video showing how it worked using I2C and one-wire bus examples, the video generated a lot of comments.

This video is somewhat of a follow-up showing how to set the device up using Zadig and Pulseview, I also do a teardown to show what's inside. Finally, these cheap Saleae clones are not the only low-cost option for the hobbyist; I setup a Pi Pico as a logic analyzer and compare its performance to the Saleae clone.

Overall, I'm still impressed with the bargain Saleae compatible device from AliExpress, for the bargain price it's a versatile tool for any hobbyist!
